ZPMC reach stacker ZHRS45 - the ultimate solution for efficient container handling!
With its superior performance and cutting-edge technology, the ZPMC reach stacker ZHRS45 is the ideal choice for heavy lifting and moving containers in ports, terminals, warehouses, and logistics centers.
Featuring a powerful engine and robust hydraulic system, this ZPMC reach stacker ZHRS45 delivers exceptional lifting capacity of up to 45 tons and can easily handle 20-foot, 40-foot containers with ease.
ZPMC reach stacker ZHRS45 comes equipped with advanced safety features such as an anti-tipping system, overload protection, and a spacious cabin with excellent visibility, ensuring maximum operator comfort and safety.
ZPMC Reach Stacker ZHRS45 for Sale in Zambia
ZPMC Reach Stacker ZHRS45 for Sale in Zambia
ZPMC Reach Stacker ZHRS45 for Sale in Zambia
ZPMC Reach Stacker ZHRS45 for Sale in Zambia
Lifting capacity: Max 45tons
Max. Lifting height: 15100 mm
Boom angle: 0-60°
Min. ground clearance: 320 mm
Min. turning radius: 8000 mm
Tread (front wheel/rear wheel): 3030/2790 mm
Wheelbase: 6000 mm
Dimension (length × width × height): 11258 × 6042 × 4770 mm
Dead weight: 72 t
Engine: Cummins QSM11
Power rating: 250KW at 2100 rpm
Torque rating: 1785 Nm at 1260 rpm
Transmission: DANA CLARK 14.5HR36432 4 gears
fwd/ 4 rev
Fully automatic transmission
Drive axle: Kessler D102 PL341 with wet disc
brakes
Spreader: ZPMC SPREADER
Tyres: 18.00×25 / 40 PR, Advance (Guizhou)
Colour: AS Customer’s request
